GENERAL
| Dimensions w/ Carton (WxDxH) | 628(W) x 555(D) x 460(H) mm/ 24.7 (W) x 21.9 (D) x 18.1 (H) inch | ||
| Dimensions w/o Carton | 409(W) x 466(D) x 250(H) mm/ 16.1(W) x 18.3(D) x 9.8 (H) inch | ||
| Weight w/ Carton | 22 kg/ 48.5lb | ||
| Paper Capacity | 250 sheets | ||
| MP Tray Capacity | N/A | ||
| Optional Paper Tray Capacity | N/A | ||
| Output Paper Capacity | 100 sheets Face Down 1 sheet Face Up (straight paper path) |
||
| Media Size (Standard Tray) | A4, Letter, ISOB5, A5, A5(Long Edge), ISOB6, A6, Exective, Legal, Folio | ||
| Media Weight | Standard Tray | 60 to 105 g/m² (16 to 28lb) | |
| Memory | Standard | 32MB | |
| Option | Maximum up to 544MB using 1 slot (144pin SO-DIMM) (maximum one 512MB DIMM can be attached) | ||
| LCD | 1-line, 16 characters | ||
| PC Interface | Hi-Speed USB 2.0 Ethernet 10/100 Base-TX |
||
PRINTER
| Speed (A4/ LTR) | Monochrome | up to 16 ppm/ up to 17ppm | |
| Full Color | up to 16 ppm/ up to 17ppm | ||
| Resolution | 600 x 600 dpi 2400 dpi (2400 x 600) quality Vertical x Horizontal resolution |
||
| Printer Driver Utility | Color restriction tool from printer driver *1 | ||
| Emulation | N/A(Host-Based only) | ||
| Resident Fonts | PCL | N/A | |
| BR-Script 3 (PostScript® 3 language emulation) | N/A | ||
NETWORK
| Support Protocols | IPv4 | NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server,TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP,POP before SMTP, SMTP-AUTH SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint, SSL/TLS | |
| IPv6 | BRAdmin Professional 3 for Windows (Brother original Windows utility for printer and print server management) (Download from http://solutions.brother.com) | ||
Operating System
| For Windows® user | Host-Based for Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008 | ||
| For Macintosh® user | Macintosh Printer Driver for Mac OS X 10.3.9 or greater | ||
| For Linux user | Linux printer driver for CUPS printing system (x86 , x64 environment) Linux printer driver for LPD/LPRng printing system(x86 , x64 environment) | ||
